The L Series oil-injected rotary screw compressors provide a range that combines high performance, low operating costs and reliability with ease of installation and servicing. Industries both large and small rely on Champion rotary screw compressors for a constant supply of high-quality compressed air. Specifications and Features: 10HP Pressure at 100 psig 44.5 CFM at 100 psig Fixed Speed Base Mounted 2-Year Warranty Factory Filled with CompLube 8000



Features

• Compact design which gives you a small footprint.
• TEFC High Efficiency Motor.
• Quiet Enclosure to reduce sound levels.
• Wye/Delta Starter.
• Delcos Microprocessor based control system.
• Automatic belt tensioning system.



Technical

Dimensions (L x W x H)	27 x 25 x 41	inch
Power supply	208-230, 460 / 60 / 3ph	V/Hz/A
Weight approx.	452	lbs



Options

27-L07AC125TV	Champion 10HP, Rotary Screw Fixed Speed Compressor, 125 PSIG, 208-230/460/3/61	$11,635.00	Add to cart
27-L07AC125TVAS-8	Champion 10HP AirStation, Rotary Screw Fixed Speed Compressor, 125 PSIG, 208-230/460/3/60, 80 Gallon Tank, With Dryer	$14,274.00	Add to cart
27-L07AC125TVAS12	Champion 10HP AirStation, Rotary Screw Fixed Speed Compressor, 125 PSIG, 208-230/460/3/60, 120 Gallon Tank, With Dryer	$14,455.00	Add to cart
27-L07AC145TV	Champion 10HP, Rotary Screw Fixed Speed Compressor, 145 PSIG, 208-230/460/3/60	$11,635.00	Add to cart
27-L07AC190TV	Champion 10HP, Rotary Screw Fixed Speed Compressor, 190 PSIG, 208-230/460/3/60	$11,635.00	Add to cart
27-PA204-2337	Warranty Kit for LV05-LV07	$615.00	Add to cart



Accessories

27-28H369	CompLube 8000 advanced, synthetic lubricant for CompAir rotary screw compressors -- 2.5 Gallon	$634.00	Add to cart
27-28H388	CompLube 8000 advanced, synthetic lubricant for CompAir rotary screw compressors	$1,102.00	Add to cart
27-PA204-2209	CompAir L07-L11 Platinum Warranty Kit	$602.00	Add to cart
